  • 22TA-WR-BA-0502-20
  • 22TA-WR/22TA-WR-S/22TA-WR-BA

    22TA-WR/22TA-WR-S/22TA-WR-BA

    BASIC CULTURE

    Features:



    Pleat Height:15mm/20mm/25mm/35mm/45mm

Product Description

22TA-WR series use standard plain weave fabrics, after our environmental friendly coating and pleating, the fabrics of 22TA-WR series have water repellency,very good performance in color and appearance. Color is vivid and stable and flatness of pleating is appreciated by our clients. Pearlized coated with Merck's Pearlize powder from Germany.  It's complies with Oeko-Tex 100 and GREENGUARD standard.

22TA-WR: Basic dim out pleated shades fabrics, good in pleating shape's recovery, good water repellency in front side,and easy for the processing ( ok for cold knife). Totally 9 standard color.

22TA-WR-S: Pearlized coated in back side, good water repellency in front side,vivid color. Totally 9 standard color .

22TA-WR-BA: 100% blackout, good water repellency in front and back side,vivid color. Totally 9 standard color .

Customized color available, standard pleated height is 20 mm, but 15 to 50 mm is also available, maximum width is 2800 mm.

Features







Specifications

Series

22TA-WR

22TA-WR-S

22TA-WR-BA

Features

dim out

pearlized backing

blackout

Composition

100% Polyester

100% Polyester

100% Polyester

Coating Material

PU

PU

PU

Standard Width

2800mm

2800mm

2400mm

Mesh Weight

Abt. 130g/m2

Abt. 150g/m2

Abt. 300g/m2

Thickness

Abt. 0.3mm

Abt. 0.3mm

Abt. 0.45mm

PVC Content

Free

Free

Free

Shading Rate

>50%

>65%

100%

UV-Blocking

>99%

>99%

100%

Color Fastness

≥4-5 Grade

≥4-5 Grade

≥4-5 Grade

Pvc Content

Not Detectable

Not Detectable

Not Detectable

Extractable Metal Content

Not Detectable

Not Detectable

Not Detectable

Sensitizing And Carcinogenic Content

Not Detectable

Not Detectable

Not Detectable

Water Repellent  Standard

ISO4920:4

AATCC22:90

 GB/T 4745:4

ISO4920:4

AATCC22:90

 GB/T 4745:4

ISO4920:4

AATCC22:90

 GB/T 4745:4

Flame Retardant Standard

——

——

——



Production Process





Applicable System & Accessories

Day-night system Up-Down matching system Ball chain controlled system with auto-lowering function
It combines the function of rope system and auto-lowering characteristics, perfectly unity of the day blinds and night blinds. It combines the function of rope system and auto-lowering characteristics, perfectly unity of the day blinds and night blinds. Just with a soft pull of the ball chain, then the blind will fall down with uniform speed by itself.
TDBUaccordion system cordlock system Arc-shaped motorized system
It uses a special circular rope in the system. Just with a soft push of the handle, then it can adjust the sun-light according to the needs. Besides, this system is also an expansion and interpretation to the skylights.

Color match design: Headrail, bottom rail, fabric, cord and knob are color totally matched and coordinated.
High quality cord makes the blinds endurable and long life. Can be controlled at right side or left side in accordance with diversified requirement.

This system is also available for day and night blinds.
Motorized system adopts high-end imported motors, with multiple advantages such as low noisy, low energy consumption and long service life. It can also provide you the best comfortable control experience, with different control method such as wall switch, remote wireless, and intelligent control method.



Application



Packaging Information









Fabric length: 30m + 5m per carton

MOQ: 500m / color

Pleated Height:20mm

Carton L W H
Packing Size 96" 16" 1.6"

Pleated Height:25mm

Carton L W H
Packing Size 96" 16" 2.0"

Pleated Height:35mm

Carton L W H
Packing Size 96" 16" 2.4"
